P0030 HO2S Heater Control Circuit B1S1 OBD-II Trouble Code Technical Description Article byDale ToalstonASE Certified TechnicianGeneric: HO2S Heater Control Circuit (Bank 1 Sensor 1) GM: HO2S Healer Control Circuit Conditions What does that mean? For an engine to run properly, there needs to be a very specific air:fuel ratio of 14.7:1. To accomplish this the ECM (Engine control module) relies on the the Heated Oxygen sensors (HO2S). The HO2S detect oxygen content in the exhaust. This information is then relayed to the ECM. The ECM uses this information to adjust the fuel delivered to the engine. A Heated Oxygen sensor contains a circuit dedicated to operating a heater that warms up the Oxygen sensor faster than the exhaust gasses could. This shortens the time the engine needs to achieve closed loop, which decreases emissions. On some vehicles the O2 sensor heater is fed a 12V fused supply voltage and a computer controlled ground. The 12V supply voltage is supplied to the heater anytime the key is in the on position.

The computer activates the heater under certain circumstances by completing the ground to the oxygen sensor heater. On other vehicles the O2 sensor heater may be supplied a computer controlled 12 volts feed and continuous ground. If the ECM detects a fault on the Bank 1, sensor 1 heater circuit a P0030 may set. Symptoms of a P0030 DTC may include: Lengthened time needed to achieve closed loop MIL (Malfunction indicator lamp) illuminationcarrier 13 seer air conditioner cost Possibly decreased fuel mileage depending on faultdx split air conditioning units Potential causes of a P0030 trouble code may include:haier window ac unit manual Failed or damaged heater circuit element inside the HO2S Open on the O2 sensor heater's ground circuit

Open or short on O2 sensor heater's B+ battery feed (on some vehicles this may be the control circuit) Possible ECM failure (less likely) Many times a HO2 sensors heater element may go bad due to age or impact. Keep this in mind when making your inspection. Make a visual inspection of the Bank 1,1 O2 sensor. Repair any damaged wiring from contact with exhaust. If HO2 Sensor itself appears to have been damaged, replace it. If a visual inspection reveals no obvious problems, viewing the faulty heater circuit on a scan tool may reveal if the fault is currently occurring. If the scan tool datastream shows that the Bank 1,1 heater element is pulling 0 amps then suspect an open in the circuit. Check for blown fuses and then disconnect the O2 sensor connector. With key on engine off use a voltmeter to check for 12 volts fused battery feed to the heater element. If there is no voltage present, repair open or short in the B+ feed circuit remembering to replace any fuse blown from the short.

If the B+ battery feed is intact, remove the ground (control) circuit from the ECM wiring connector and check for resistance on the circuit. If there is infinite resistance, repair open in the circuit. If the control circuit checks out, suspect a bad O2 sensor. Register now to ask a question (free) Related P0030 DTC DiscussionsTrouble with '06 pathfinder p0030O6 pathfinder...began to shake while idling at light n service engine light came on. Had oreily auto parts scan for codes. Showed coil for cylinder #1 to be faulty. Replaced with used coil. Problem seemed to b fixed. Drove 1 mile or so to autoparts store cause i broke battery terminal while putting ... GLS 2013 Elantra 1.8L Hyundai P0030 P0135 P2118 codesI have three codes that I already know one of them they are p0135 p2118 and p0030 P0135 I know what it is already but need help with the other two... 2006 Ford Focus Engine light P0030 P0037 P0050 P0057hi, I have got Ford focus 2006 1.6 petrol zetec 5dr, engine light came on

few days ago, i used code reader turn the light off two times but it comes back with these codes, P0030, P0037, P0050, P0057.My question is why it comes with these four codes at a time, is there a big fault?or should iMini Cooper R56 p0030 O2 sensorPlease help I have a p0030 code come up on my 2007 Mini Cooper R56. Where Is the location of the lambda sensors and does the "bank 1 sensor 1" mean that it is the sensor pre or post cat?2006 chevrolet trailblazer OBD code p0030where is the HO2S Heater Control Circuit Bank 1 Sensor 1 on a 06 trailblazer... Need more help with a p0030 code? If you still need help regarding the P0030 trouble code, please post your question in our FREE car repair forums. NOTE: This information is presented for information purposes only. It is not intended as repair advice and we are not responsible for any actions you take on any vehicle. All information on this site is copyright protected. If you want to share this article or information with others, please link to
