$0.00 - $36.00$36.00 - $47.00$47.00 - $58.00$58.00 - $69.00$69.00 - $80.00 OEM Brose HELLA Bosch DELPHI Lear Siemens Eaton DEPO Harman Kardon HomeAC /HeatingClimate Control Display Alphabetical: A to Z Alphabetical: Z to A 00 BMW E46 323 AC HEATER CLIMATE CONTROL DISPLAY UNIT 6 902 440 00 BMW E46 328i AC HEATER CLIMATE CONTROL DISPLAY UNIT 8382447 01 BMW E46 330 325 AC HEATER CLIMATE CONTROL DISPLAY UNIT 6 914 009 01 BMW E46 M3 330 328 AC HEATER CLIMATE CONTROL DISPLAY UNIT 6 907 897 01 BMW E60 525i 530i M5 AC HEATER CLIMATE CONTROL UNIT TRIM 6 988 505 05 BMW E46 330 325 AC HEATER CLIMATE CONTROL DISPLAY UNIT 06 BMW E90 330i 328i Dash Climate Control AC Heater Control Module 9 110 610 BMW E38 740 HEATER AIR CONDITIONER CLIMATE CONTROL MODULE 6 901 314 Click here to order! The BMW E46 IHKA (Integriertes Heizung und Klima automatic), or integrated automatic climate control system, provides the vehicle cabin with heating, air-conditioning and ventilation.

The main components and features of this system are as follows:Single heater core uses circulating engine coolant to provide cabin heat and window defrosting functionBlower control via final stage (blower motor resistor pack)A/C compressor is electronically controlledAir distribution and fresh air volume dependent on vehicle road speedAir distribution controlled by self-calibrating stepper motors powered via M-busDefrost function calls maximum heating and cooling automaticallyRear window defogger and heated outside rear view mirrors integrated into the climate control systemFresh air microfilterHeating and air-conditioning can be personalized via Car Memory / Key Memory functionThe IHKA panel is the main control for the climate control system. The panel can fail over time, losing functions in one or more buttons. When this happens, your interior climate control does not function normally. This technical article will show you how to remove and replace your IHKA control panel.Keep in mind that when your car was serviced before, parts may have been replaced with different size fasteners used in the replacement.

The sizes of the nuts and bolts we give may be different from what you have, so be prepared with different size sockets and wrenches. Protect your eyes, hands and body from fluids, dust and debris while working on your vehicle. If you are working with the electrical system, disconnect the battery before beginning. Always catch fluids in appropriate containers and properly dispose of any fluid waste. Recycle parts, packaging and fluids when possible. Do not work on your vehicle if you feel the task is beyond your ability. trane ac repair dallasVehicle models change and evolve as they grow older, so the vehicle shown in our illustrations may vary slightly from yours. dual zone hvac conversionIf something seems different, let us know and share your info to help other users. wine cellar cooling units nz

Do you have questions or want to add to the article? Leave a comment below. When leaving a comment, please leave your vehicle information. Open the storage compartment door. Then push the center of the compartment upward to release the locking tabs and pull the compartment out of the dashboard. Pull up on the shifter bezel (automatic transmission) or shift boot (manual transmission) (depending on equipment) to unclip from the center console. Automatic transmission: Disconnect the shifter bezel electrical connectors (green arrows). Remove the shifter bezel fasteners (green arrows). Next, disconnect the electrical connectors (green arrows) then remove the shifter bezel. Remove the trim panel fasteners (green arrows). Pull the trim panel with the ashtray up and away from the center console. Then reach up behind the IHKA control panel and push it out toward the rear of the vehicle. Disconnect the IHKA panel electrical connector by releasing the lever lock and rotating it up and pull the connector out of the panel (purple arrow).

Then disconnect the additional electrical connectors by releasing their tabs and pulling them out (green arrows). Remove the panel from the vehicle. Install the new IHKA panel in reverse order or removing. Be sure to route the wiring as it was before and confirm all the electrical connectors are properly seated. View Cart & CheckOut |  Recommend this page to a friend... Copyright © Pelican Parts Inc.BMW instrument cluster LCD display pixel failure repair ribbon cable KIT for E38 E39 M5 X5 **SILVER cable + repair VIDEO+ needle removal tool** BMW 3 series (E36), 5 series (E34, E39), 7 series (E38), 8 series (E31), X5 from 1988-2003 all have the common dead / fading / disappearing pixels on the dashboard instrument cluster / speedometer (also on the board computer) - on the large LCD display that shows valuable data such as the mileage and the on board computer messages. You will find OBC LCD display ribbon cable KITs for the following models / units below:BMW E31 MID BMW E34 instrument clusterBMW E36 MIDBMW E38 Air Conditioning (A/C) control unitBMW E38 Multi information display MID (Also called as "On board computer/OBC")BMW E38 / E39 / X5 instrument cluster (speedometer) BMW E39 / X5 Multi information display MID (Also called as "On board computer/OBC")
