With the X-CUBE compact TROX has created a ready-to-operate and pre-configured air handling unit that combines the excellent features of the X-CUBE in the smallest of spaces. These units handle volume flow rates of 600 to 6,000 m³/h and offer a heat recovery efficiency of over 80 % (dry, to EN 308), hence they are the ideal solution for small and midrange applications. TROX offers nine different X-CUBE compact units with a choice of two different heat recovery systems..Top performance, small size Volume flow rates of 600 to 6,000 m³/h Powerful EC fans also for high external differential pressures High level of hygiene (conforms to VDI 6022) Heat recovery with heat wheel or counter flow plate heat exchanger Air filtration with TROX minipleat or NanoWave filters Ready-to-operate unit (plug and play) Operating side can be changed at a later stage Integral, bus compatible control technology Advantages at a glance Seamless integration into modern building management systems

The X-CUBE CROFCU is a compact ventilation unit that ensures and maintains the essential conditions for all classes of clean rooms. The secondary unit for use with centralised ventilation and air conditioning systems is typically installed in false ceilings. It dissipates high thermal loads and requires only a low fresh air volume flow. The primary air system (patent pending) allows for the direct removal of exhaust air while fresh air is supplied to the room. Suitable for all clean room concepts Pumped chilled water cooling system with room temperature control Increased flexibility if several units are connected Energy-efficient plug fan with EC motor Addition of fresh air from 50 m3/h to 2000 m3/h Monitoring of filters downstream Control of airlocks for people and material Contamination check by means of pressure zone control Space-saving due to smaller ducts Simple and quick commissioning due to plug and play With the TROX X-CUBE, an air handling unit with unlimited configuration options, TROX sets a new standard in the AHU market and defines considerably higher levels of quality, performance, flexibility, reliability, energy efficiency, and hygiene.

Compelling all down the line. TROX now offers everything from a single source: air handling units and components – ideally complementary to each other.For even more energy efficiency and better quality with less coordination effort. For the ventilation of rooms and entire buildings, for filtering, heating, and cooling the air, for heat recovery as well as for humidification and dehumidification, and for volume flow rates of up to 86,000 m³/h Flexible frame construction, completely covered externally by thermally insulated panels or doors Easy installation, maintenance and cleaning Special hygiene construction variant according to AHU Guideline 01 (RLT-Richtlinie 01) for use in hospitals and laboratories; weatherproof construction variant for outdoor installationOur centrifugal fans with free running impellers are designed for installation into appliances such as air handling units. An air handling unit is a factory-made case assembly consisting of a fan or fans and other necessary equipment to perform one or more of the functions of circulating, cleaning, heating, cooling, humidifying, dehumidifying and mixing of air.

Small air handlers for local use, are called terminal units. The air handler us normally constructed around a framing system with metal infill panels as required to suit the configuration of the components. The AHU is used to control the following parameters of the space. There are basically two types of air handling unit that are used; amana ptac hvac units In the Draw-Through type, the fan pulls the air through the mixing box, filters and cooling coil before discharging it from the fan outlet to the space to be conditioned or to the ducting network. aon ac unitIn this case, the section before the fan has negative pressure.window unit air conditioner mold and mildew In the Blow-Through type, the fan blows the air through the mixing box, filters and cooling coil before discharging them to the space being conditioned or the ducting system.

In air handling units, centrifugal fans are used to circulate the air to the various parts of the sections in the building. The selection of the fan will depend on the air volume and the static pressure required of the system. Usually, the designer of the system will use a specialised software to do this selection. In order to reduce the effect of vibration on the panel, the motor and the fan are usually installed on the vibration isolator except when the drive assembly is external to the fan casing. The use of variable air volume (VAV) systems is becoming more popular as the volume of the air being discharged can be varied depending on the load condition. If the load is high, the fan speed will be higher and if the load is lower, the speed of the fan will be lower. The speed of the fan is varied using a frequency inverter instead of a conventional motor. A whole range of fan speed from super low to super high can now be utilised based on the load conditions required, therefore a frequency inverter can provide better control of the fan speed.

A greater focus on the development in EC technology has enabled better use of energy and is in line with the move to more energy efficient products (ERP). The requirements on a ventilation system are not always the same. In many applications, all that is required is a straightforward exchange of air, whereas in other applications the requirements can vary according to the temperature, humidity and purity of the air. Noise is also a significant factor to consider when choosing AHU fan components. Axair Fans can supply components for efficient air movement within air handling units including backward curved impellers, EC forward curved centrifugal fans and belt driven options where required. Our high performance centrifugal impeller without spiral housing, the E-Series “REVOLUTION” is a range specifically designed for volume flow. Manufactured from aluminium, the E range is designed and manufactured especially for the use of larger volume flow and lower pressure coupled with superior noise reduction and quiet operation.

The impellers are manufactured using a black, UV-stabilised, long glass-fibre reinforced polypropylene. Weighing 1.22 kg/m³, the impellers are extremely lightweight when compared with aluminium or steel alternatives. Therefore, the mass of inertia and start-up resistance is minimal. With improved dirt resistance, In-balance during operation is effectively eliminated. When used with an Electronically Commutated Motor (EC-Motor) or an AC-External Rotor Motor, Axair centrifugal fans with reduced noise, free-running, backward curved, high performance impellers make a very compact, efficient and optimally designed fan unit. The fan units are available as: Combining highly automated impeller manufacturing, efficient sheet metal processing and Rosenberg developed EC-Motors or voltage controllable AC-External Rotor Motors enables us to manufacture fan modules which offer optimum performance for customers, while been optimally matched with the construction needs of the end application.
